AWS79062SPR

Low Noise, RRIO CMOS Op-amps with 10MHz Bandwidth

Datasheet :
Preview - AWS79062SPR - Datasheet
Ref.Price
  • 1-99￥2.64
  • 100-249￥2.16
  • 250-499￥1.74
  • 500-999￥1.37
  • 1000+￥1.05

Product details

Channel 2
Power Supply (Min) (V) 1.8
Power Supply (Max) (V) 5.5
Vos@25℃ (Max) (mV) 1.6
Vos TC (Typ) (µV/℃) 0.5
GBW (Typ) (MHz) 10
Slew rate (Typ) (V/us) 13
Iq per channel (Typ) (mA) 0.85
Vn @ 1 kHz (Typ) (nV/rtHz) 13
CMRR (Typ) (dB) 99
Rail-to-rail in,out
Temperature -40℃~125℃
IB (Typ) (pA) 1
Package SOP-8L
SOP-8L
宽电源电压范围: 1.8V ~ 5.5V 低输入失调电压: ± 0.4mV 转换率: 13V/μ s 低输入偏置电流: 1pA 低宽带噪声: 13nV/√Hz 低静态电流: 850μA/CH 轨到轨输入和输出 带宽: 10MHz 灌电流和源电流能力: 50mA
The AWS7906X is a high precision, low-power, low-voltage (1.8V to 5.5V) operational amplifiers with rail-to-rail input and output swing capabilities, which makes it ideal to general-purpose applications. This op amp features very good AC performance with a gain-bandwidth product of 10MHz, slew rate of 13V/μs and low input voltage noise of 3.8μVpp, while drawing 850μA per channel (typical) quiescent current. It has an input common-mode voltage range that extends to each supply rail, and its outputs swing to within 27mV of the supply rails with a 2kΩ load. The AWS7906X provides an appropriate solution for space-constrained applications such as battery powered IoT devices, wearable electronics, and personal electronics where minimum PCB footprint is required.

Technical documentation
Type
Title
Date
Datasheet DS_AWS7906X_EN_V1.8   2025-12-29

Design & development

For additional terms or required resources, click any title below to view the detail page where available.

Hardware development

Evaluation board

AWS790X2SPR EVB V1.0 — AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.

AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.
