| Power Supply (Min) (V) |
2.5 |
| Power Supply (Max) (V) |
5.5 |
| PO(W)（8Ω&THD=1%） |
1.35W@5V |
| SPK
Noise(uV) |
55uV@6dB |
| Protection |
/ |
| Control Interface |
GPIO |
| Temperature |
-40℃~85℃ |
| Package (mm) |
FCQFN 1.5X1.5-9L |
• RNS (RF-TDD Noise Suppression)
• EEE Function, Greatly reduces EMI over the full bandwidth
• Excellent Pop-Click Supression
• High PSRR (70dB at 217Hz)
• Support 1.8V Control
• 0.1%THD+N（Pout=0.4W,VDD=4.2V）
• Up to 90% Efficiency
• Low Quiescent Current (2.6mA)
• Low Shutdown Current (<0.1uA)
• Over-Current Protection
• Over-Temperature Protection
• ESD: ±6kV (HBM)
• Latch-Up：±450mA
• Small 1.5mm×1.5mm FC-9 Package
The AW8010A is a ultra-low-EMI, RNS, mono, filter-free, Class-D audio amplifier. Unique RNS, which effectively reduces RF energy, attenuate the RF TDD-noise.
The AW8010A features the EEE (Enhanced Emission Elimination) function which greatly reduces EMI over the full bandwidth. The AW8010A achieves better than 20dB margin under FCC limits with 24 inch of cable.
The AW8010A built-in timing control module for Pop-Click Supression, effectively eliminate the transient noise that during power-on, power-off, wake up, and shutdown.
The AW8010A built-in over-current protection and over-temperature protection function, effectively protect the chip.
The AW8010A is available in an ultra small 1. 5mm×1. 5mm FC-9 package. The AW8010A is specified over the industrial temperature range of -40℃ to +85℃.
