| Channel | 144 |
| Global Current Level | 1 |
| Current Levels for Color-Mixing | 1 |
| Current Levels for Dimming | 256 |
| Charging Indicator | NO |
| Control Interface | IIC SPI |
| Power Supply (Max) (V) | 5.5 |
| Global Max Current(mA) | 40 |
| IO Level (V) | 1.8 3.3 |
| Audio Sync. | NO |
| Power Supply (Min) (V) | 2.7 |
| Auto Breath | NO |
| Temperature | -40℃~105℃ |
| Topology | Matrix |
| Package (mm) | EQFP 7X7-48L |
| EQFP 7X7-48L |
|
Type
|
Title
|
Language
|
Date | |||
|---|---|---|---|---|---|---|
| Datasheet | DS_AW20144SQPY_EN_V1.0 | 英文 | 2026-10-09 |
Evaluation board
AW20216SQPY_EVB_V1.0 — EVB evaluation board for Awinic matrix LED drive
AW20216SQPY_EVB_V1.0 is an Awinic matrix LED drive demonstration board. When paired with a light board and GUI, it can demonstrate matrix LED functionality.
APPLICATION SOFTWARE&FRAMEWORK
AW20144SQPY_AW20216SQPY_GUI — AW20144SQPY/AW20216SQPY tunning tools
AW20144SQPY_AW20216SQPY_GUI is a highly integrated and easy-to-use tool for product configuration and debugging.Intuitive interface and user-friendly operation can help custion can help customers shorten development cycle and complete system integration quickly
Evaluation board
AW20216SQPY_EVB_V1.0 — EVB evaluation board for Awinic matrix LED drive
AW20216SQPY_EVB_V1.0 is an Awinic matrix LED drive demonstration board. When paired with a light board and GUI, it can demonstrate matrix LED functionality.
APPLICATION SOFTWARE&FRAMEWORK
AW20144SQPY_AW20216SQPY_GUI — AW20144SQPY/AW20216SQPY tunning tools
AW20144SQPY_AW20216SQPY_GUI is a highly integrated and easy-to-use tool for product configuration and debugging.Intuitive interface and user-friendly operation can help custion can help customers shorten development cycle and complete system integration quickly
