AWS79652SPR

Low Noise, 6MHz, High Precision Zero-Drift, RRIO Op-amps

Datasheet :

Preview - AWS79652SPR - Datasheet

Ref.Price

1-99￥5.28
100-249￥4.33
250-499￥3.48
500-999￥2.74
1000+￥2.11

Product details

Channel	2
Power Supply (Min) (V)	1.8
Power Supply (Max) (V)	5.5
Vos@25℃ (Max) (mV)	0.0085
Vos TC (Typ) (µV/℃)	0.03
GBW (Typ) (MHz)	6
Slew rate (Typ) (V/us)	5.5
Iq per channel (Typ) (mA)	1.1
Vn @ 1 kHz (Typ) (nV/rtHz)	12
CMRR (Typ) (dB)	130
Rail-to-rail	in,out
Temperature	-40℃~125℃
IB (Typ) (pA)	10
Package	SOP-8L

SOP-8L

Very high accuracy and stability: offset voltage 8.5μV max. at 25 °C Wide Supply Voltage Range:1.8V ~ 5.5V Slew Rate: 5.5V/μs Low Input Voltage Noise: 12nV/√Hz Low Quiescent Current: 1100μA/CH Rail-to-Rail Input and Output Bandwidth: 6MHz Sink and Source Current Capability: 87mA SOP - 8L packages

The AWS79652 is a dual channel low power, high precision Zero-Drift CMOS operational amplifier. The device can operate from 1.8V to 5.5V single supply or from ±0.9V to ±2.75V dual supplies. This op amp features very good AC performance with a gain bandwidth product of 6MHz, slew rate of 5.5V/μs and low input voltage noise of 0.25μVpp, while drawing 1100μA per channel (typical) quiescent current. The AWS79652 also support rail-to-rail input and output. The AWS79652 is designed to provide optimal performance in low voltage and low power systems. It has high impedance inputs and 8.5μV (Max) offset voltage. These specifications make AWS79652 appropriate for a wide range of applications requiring high precision, such as high linearity driver of high precision ADC. The AWS79652 is available in Green SOP-8L package.

Technical documentation

	Type	Title			Date
	Datasheet	DS_AWS79652_EN_V1.0			2025-04-24
	New product launch	【New Product Launch】Awinic Launches Dual-Channel Zero-Drift Operational Amplifier AWS796X2 Series			2026-02-11

Design & development

For additional terms or required resources, click any title below to view the detail page where available.

Hardware development

Evaluation board

AWS790X2SPR EVB V1.0 — AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.

AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.
