AWS79064SPR

Low Noise, RRIO CMOS Op-amps with 10MHz Bandwidth

Datasheet :
Preview - AWS79064SPR - Datasheet
Ref.Price
  • 1-99￥3.85
  • 100-249￥3.16
  • 250-499￥2.54
  • 500-999￥2.00
  • 1000+￥1.54

Product details

Channel 4
Power Supply (Min) (V) 1.8
Power Supply (Max) (V) 5.5
Vos@25℃ (Max) (mV) 1.6
Vos TC (Typ) (µV/℃) 0.5
GBW (Typ) (MHz) 10
Slew rate (Typ) (V/us) 13
Iq per channel (Typ) (mA) 0.85
Vn @ 1 kHz (Typ) (nV/rtHz) 13
CMRR (Typ) (dB) 99
Rail-to-rail in,out
Temperature -40℃~125℃
IB (Typ) (pA) 1
Package SOP-14L
SOP-14L
宽电源电压范围: 1.8V ~ 5.5V 低输入失调电压: ± 0.4mV 转换率: 13V/μ s 低输入偏置电流: 1pA 低宽带噪声: 13nV/√Hz 低静态电流: 850μA/CH 轨到轨输入和输出 带宽: 10MHz 灌电流和源电流能力: 50mA
The AWS7906X is a high precision, low-power, low-voltage (1.8V to 5.5V) operational amplifiers with rail-to-rail input and output swing capabilities, which makes it ideal to general-purpose applications. This op amp features very good AC performance with a gain-bandwidth product of 10MHz, slew rate of 13V/μs and low input voltage noise of 3.8μVpp, while drawing 850μA per channel (typical) quiescent current. It has an input common-mode voltage range that extends to each supply rail, and its outputs swing to within 27mV of the supply rails with a 2kΩ load. The AWS7906X provides an appropriate solution for space-constrained applications such as battery powered IoT devices, wearable electronics, and personal electronics where minimum PCB footprint is required.

Technical documentation
Type
Title
Date
Datasheet DS_AWS7906X_EN_V1.8   2025-12-29

Design & development

For additional terms or required resources, click any title below to view the detail page where available.

Hardware development

Evaluation board

AWS722X4SPR_EVB_V1.0 — The AWS722X4SPR EVB is a high-voltage general-purpose operational amplifier test board developed by Aiwei. The key test points of the chip are individually led out on the EVB board using SMA interfaces for easy demonstration and testing;

EVB evaluation board for operational amplifier AWS722X4SPR.
