AWS79062SPR-Q1

Low Noise, RRIO CMOS Op-amps with 10MHz Bandwidth

Datasheet :
Preview - AWS79062SPR-Q1 - Datasheet

Product details

Parameters

Channel 2
Power Supply (Min) (V) 1.8
Power Supply (Max) (V) 5.5
Vos@25℃ (Max) (mV) 0.9
Vos TC (Typ) (µV/℃) 0.5
GBW (Typ) (MHz) 10
Slew rate (Typ) (V/us) 13
Iq per channel (Typ) (mA) 0.85
Vn @ 1 kHz (Typ) (nV/rtHz) 13
CMRR (Typ) (dB) 99
Rail-to-rail in,out
Temperature -40℃~125℃
IB (Typ) (pA) 1
Package SOP-8L

Package | Pins | Size

SOP-8L

Features

Qualified for Automotive Applications AEC - Q100 Qualified with Grade 1 Wide Supply Voltage Range:1.8 V ~ 5.5 V Low Input Offset Voltage: ±0.4 mV Slew Rate: 13 V/μs Low Input Bias Current: 1 pA Low Broadband Noise: 13 nV/√Hz Low Quiescent Current: 850 μA/CH Rail-to-Rail Input and Output Bandwidth: 10 MHz Sink and Source Current Capability: 50 mA

Description

The AWS7906X-Q1 is a high precision, low-power, low-voltage (1.8 V to 5.5 V) operational amplifiers with rail-to-rail input and output swing capabilities, which makes it ideal to general-purpose applications. This op amp features very good AC performance with a gain-bandwidth product of 10 MHz, slew rate of 13 V/μs and low input voltage noise of 3.8 μVpp, while drawing 850 μA per channel (typical) quiescent current. It has an input common-mode voltage range that extends to each supply rail, and its outputs swing to within 27 mV of the supply rails with a 2 kΩ load. The device is AEC-Q100 qualified (Automotive Electronics Council (AEC) standard Q100 Grade 1) and it is suitable for automotive applications. The AWS7906X-Q1 is available in Green SOP - 8L and SOP - 14L packages. It operates over an ambient temperature range of -40 °C to +125 °C.

Technical documentation
Type
Title
Language
Date
Datasheet DS_AWS7906X-Q1_EN_V1.1 英文   2025-08-28

Design & development

For additional terms or required resources, click any title below to view the detail page where available.

Hardware development

Evaluation board

AWS790X2SPR EVB V1.0 — AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.

AWS790X2SPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2SPR.
