AWS79052MPR

Low Noise, RRIO CMOS Op-amps with 8MHz Bandwidth

Datasheet :

Preview - AWS79052MPR - Datasheet

Ref.Price

1-99￥2.43
100-249￥2.00
250-499￥1.61
500-999￥1.27
1000+￥0.97

Product details

Channel	2
Power Supply (Min) (V)	1.8
Power Supply (Max) (V)	5.5
Vos@25℃ (Max) (mV)	1.6
Vos TC (Typ) (µV/℃)	1
GBW (Typ) (MHz)	8
Slew rate (Typ) (V/us)	5
Iq per channel (Typ) (mA)	0.525
Vn @ 1 kHz (Typ) (nV/rtHz)	13
CMRR (Typ) (dB)	100
Rail-to-rail	in,out
Temperature	-40℃~125℃
IB (Typ) (pA)	1
Package	MSOP-8L

MSOP-8L

Wide Supply Voltage Range:1.8V ~ 5.5V Low Input Offset Voltage: ±0.4mV Slew Rate: 5V/μs Low Input Bias Current: 1pA Low Broadband Noise: 13nV/√Hz Low Quiescent Current: 525μA/CH Rail-to-Rail Input ａｎｄ Output Bandwidth: 8MHz Sink and Source Current Capability: 50mA MSOP - 8L package SOT 23 - 8L package

The AWS79052 is a dual channel high precision, low-power, low-voltage (1.8V to 5.5V) operational amplifiers with rail-to-rail input and output swing capabilities, which makes it ideal to general-purpose applications. This op amp features very good AC performance with a gain-bandwidth product of 8MHz, slew rate of 5V/μs ａｎｄ low input voltage noise of 3.8μVpp, while drawing 525μA per channel (typical) quiescent current. It has an input common-mode voltage range that extends to each supply rail, and its outputs swing to within 27mV of the supply rails with a 2kΩ load. The AWS79052 provides an appropriate solution for space-constrained applications such as battery powered IoT devices, wearable electronics, and personal electronics where minimum PCB footprint is required. The AWS79052 is available in green small-size MSOP - 8L package and green SOT 23 - 8L package.

Technical documentation

	Type	Title			Date
	Datasheet	DS_AWS79052_EN_V1.3			2025-04-30

Design & development

For additional terms or required resources, click any title below to view the detail page where available.

Hardware development

Evaluation board

AWS790X2MPR_EVB_V1.0 — AWS790X2MPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2MPR.

AWS790X2MPR EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS790X2MPR.
