| Load Current (Max) (mA) | 300 |
| Power Supply (Min) (V) | 1.4 |
| Power Supply (Max) (V) | 5.5 |
| Vout (Min) (V) | 1.2 |
| Vout (Max) (V) | 1.2 |
| Iq (Typ) (μA) | 38 |
| Vdropout (mV) | 520@IOUT=300mA |
| PSRR @1KHz(dB) | 68@1kHz, IOUT=30mA |
| Output Noise (μVrms) | 60 |
| Discharge | YES |
| Output options | Fixed |
| Temperature | -40℃~85℃ |
| IO Level (V) | 1.2 |
| Package (mm) | DFN 1X1-4L |
| DFN 1X1-4L |
|
Type
|
Title
|
Language
|
Date | |||
|---|---|---|---|---|---|---|
| Datasheet | DS_AWP37034DXXX_EN_V1.3 | 英文 | 2026-07-17 |
Evaluation board
AWP37034YXXXDNR_EVB_V1.0 — AWP37034YXXXDNR_EVB_V1.0 is a high performance, low dropout LDO test board，the main test points of the chip are drawn separately on the EVB board for convenient testing;
EVB evaluation board for Low dropout LDO AWP37034DXXXDNR.
Evaluation board
AWP37034YXXXDNR_EVB_V1.0 — AWP37034YXXXDNR_EVB_V1.0 is a high performance, low dropout LDO test board，the main test points of the chip are drawn separately on the EVB board for convenient testing;
EVB evaluation board for Low dropout LDO AWP37034DXXXDNR.
