AWS70809ASBSTR

Low-Power, μP Supervisory Circuits

产品手册：

在线预览 - AWS70809ASBSTR - 产品手册

参考价格

1-99￥1.35
100-249￥1.10
250-499￥0.89
500-999￥0.70
1000+￥0.54

产品详细信息

参数

Power Supply (Min) (V)	1.0
Power Supply (Max) (V)	5.5
Threshold Voltage typ. (V)	4.0,3.08,2.93
Threshold Acurracy （%）	±2
ISUPPLY typ.(uA)	1.6
Vcc To Reset Delay typ.(us)	40
Time delay typ.(ms)	55
Reset Output	Push Pull；Active Low
Manual Reset	NO
Power Fail Input	NO
Temperature	-40℃~125℃
Watch Dog	NO
Package (mm)	SSOT23-3L

封装 | 引脚 | 尺寸

SSOT23-3L

特性

 Operating Range: 1.0V to 5.5V  Fixed Reset Time Delay: 200ms, 55ms(Only for AWS70809ASBSTR)  Low Supply Current: 1.6A (Typical)  Precision Supply Voltage Monitor : 1.8V, 2.5V, 2.93,V3V, 3.3V, 5V options  High Reset Threshold accuracy: ±2% (Typical)  Guaranteed RESETN Valid at VCC = 1V  Reset Output Types: AWS70803: Open-Drain, active Low AWS70809: Push-Pull, active Low  Package: SOT23-3L and SSOT23-3L  Temperature Range: -40°C to +125°C

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AWS7080X_EN_V1.5		英文		2026-07-07
