AWP37006QNR

产品手册：

在线预览 - AWP37006QNR - 产品手册

参考价格

1-99￥1.54
100-249￥1.26
250-499￥1.02
500-999￥0.80
1000+￥0.62

产品详细信息

参数

Load Current (mA)	400
Channel	4
Power Supply (Min) (V)	VIN1/2/3: 1.6V VIN4: 1.9V
Power Supply (Max) (V)	VIN1/2/3: 5.5V VIN4: 5.5V
Vout (V)	1.1V~3.3V
Vdropout (mV)	LDO1/2/3: 114mV@IOUT=300mA, 2.8V output LDO4: 73mV@IOUT=300mA, 2.8V output
Iq (Typ) (μA)	15
PSRR @1KHz(dB)	LDO1/2/3: 75dB@IOUT=150mA, 2.8V output, f=1kHz LDO4: 82mV@IOUT=150mA, 2.8V output, f=1kHz
Output Noise (μVrms)	LDO1/2/3: 50µVrms@IOUT=50mA, 2.8V output LDO4: 12µVrms@IOUT=50mA, 2.8V output
Discharge	YES
Output options	Programmable
Temperature	-40℃~85℃
IO Level (V)	1.2
Package (mm)	QFN 2X2-14L

封装 | 引脚 | 尺寸

QFN 2X2-14L

特性

● VIN1/2/3 input voltage range: 1.6V to 5.5V ● LDO1/2/3 output voltage range: 1.1V~3.3V ● LDO1/2/3 dropout voltage: 114mV (IOUT=300mA, 2.8V output) ● LDO1/2/3 power supply rejection ratio: typical 75dB (IOUT=150mA, 2.8V output, freq=1kHz) ● LDO1/2/3 noise: typical 50µVrms (IOUT=50mA, BW=10Hz to 100kHz, 2.8V output) ● VIN4 input voltage range: 1.9V to 5.5V ● LDO4 output voltage range: 1.1V~3.3V ● LDO4 dropout voltage: 73mV (IOUT=300mA, 2.8V output) ● LDO4 power supply rejection ratio: typical 82dB (IOUT=150mA, 2.8V output, freq=1kHz) ● LDO4 noise: typical 12µVrms (IOUT=50mA, BW=10Hz to 100KHz, 2.8V output) ● LDO1/2/3/4 output drive capability: 400mA Min. ● Available with 1.2V I/O ● Build in UVLO, OCP, SCP,OTP protection ● QFN 2mm×2mm-14L package

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AWP37006_EN_V1.0		英文		2026-07-09
	可靠性报告	Reliability Qualification Report For AWP37006QNR		英文		2026-06-18
