AWP35635QNR

产品手册：

产品详细信息

参数

BW(GHz)	0.83
Surge(V)	50
DC(V)	36
Ron (Ω)	2.5
Temperature	-40℃~105℃
IO Level (V)	1.2
Package (mm)	QFN 2X1.5-10L

封装 | 引脚 | 尺寸

QFN 2X1.5-10L

特性

 USB 2.0 Hi-speed SPST switch  Typical -3dB bandwidth: 830MHz  Over voltage protection: 4.8V typical  36V DC protection on Con_DP and Con_DM Ports  +50V surge protection on Con_DP and Con_DM  ESD Performance Con_DP / Con_DM Pins: ±15kV Contact Discharge (IEC 61000-4-2) ±20kV Air Gap Discharge (IEC 61000-4-2)  Supply voltage range: 1.65V to 5.5V  2.5Ω switch on-resistance typical  CON: 6pF typical  ICC: 30μA typical  QFN 2.0mm X1.5mm -10L package

技术文档

类型	项目标题	语言	日期
产品手册	DS_AWP35635_EN_V1.0	英文	2026-06-01
产品设计指南	AWP35635 硬件设计指南	中文	2026-06-15
产品设计指南	AWP35635 Hardware Design Guide	英文	2026-06-15
