AWD86326DNR

产品详细信息

参数

power_supply_min
PVDD (V) 28
Boost Type Boost
PO(W)(8&THD=1%) 1.5W@Vin=2.7,Vout=28V
IQ (mA) 5
ADC Channels 0
ADC (bit) 0
Capacitive Reactance 0
Control Interface GPIO
Protection /
Temperature -40℃~85℃
Package

封装 | 引脚 | 尺寸

DFN 3X3-14L

特性

 Integrated Boost DC/DC to Achieve 28V (MAX) Driven Voltage  VIN: 2.7V to 5.5V Operating Voltage Range  PWM Control Interface  High Speed Driver  Brief rise time and fall time  Low-Power Sleep Mode  Internal integrated ISNS current detection for f0 tracking  Over-Current Protection (OCP)  Over-temperature Protection(OTP)
