AW17145FCR

4xSPST MIPI Antenna Tuning Switch

产品手册：

在线预览 - AW17145FCR - 产品手册

参考价格

1-99￥3.85
100-249￥3.15
250-499￥2.54
500-999￥2.00
1000+￥1.54

产品详细信息

参数

Frequency (GHz)	0.4~3.8
Control Interface	MIPI
VDD (Min) (V)	N/A
VDD (Max) (V)	N/A
VIO (Min) (V)	1.65
VIO (Max) (V)	1.95
Vpeak (V)	50
Ron (Ω)	1.1
Coff (fF)	160
ISO (Max) (dB)	34
Temperature	-40℃~85℃
ISO (Min) (dB)	22
Package (mm)	FCQFN 1.5X1.1-10L

封装 | 引脚 | 尺寸

FCQFN 1.5X1.1-10L

特性

1、High Voltage Handling
2、Very Low On-Resistance,1.1Ω
3、Low Off- Capacitance, 160fF
4、High linear performance
5、MIPI RFFE V2.1 interface
6、Small FCQFN 1.5mm x 1.1mm x 0.37mm - 10L package
7、Single VIO supply, no VDD
8、Broadband frequency range: 0.4 to 3.8GHz

说明

The AW17145 is four single-pole-single-throw (4xSPST) antenna tuning switch, using CMOS silicon-on-insulator (SOI) process. The high voltage handling, high linear performance and very low Ron and COFF make the switch very suitable for high performance antenna tuning application. The AW17145 is perfectly compatible with MIPI RFFE V2.1 control interface. It is provided very small FCQFN 1.5mm x 1.1mm x 0.37mm – 10L package.

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AW17145FCR_EN_V1.0		英文		2023-06-06
