AWP37579GCSR

Triple Outputs Switching Converter for AMOLED Display

产品手册：

在线预览 - AWP37579GCSR - 产品手册

参考价格

1-99￥13.46
100-249￥11.04
250-499￥8.88
500-999￥7.00
1000+￥5.38

产品详细信息

参数

Control Interface	one-wire
ELVDD (Min) (V)	4.6
ELVDD (Max) (V)	5.0
ELVSS (Min) (V)	-6.6
ELVSS (Max) (V)	-0.5
AVDD (Min) (V)	6.5
AVDD (Max) (V)	8.0
Maximum ELVDD/ELVSS Current (mA)	1000
Maximum AVDD Current (mA)	150
Temperature	-40℃~85℃
Power Supply (Min) (V)	2.5
Power Supply (Max) (V)	4.8
IO Level (V)	1.2
Package (mm)	WLCSP 2.017X2.017-25B

封装 | 引脚 | 尺寸

WLCSP 2.017X2.017-25B

特性

Input voltage: 2.5V ~ 4.8V Excellent line and load transient response Programmable output voltage by ESWIRE from 4.6V to 5V in 100mV steps (Default: 4.6V) Programmable output voltage by ESWIRE from -6.6V to -0.5V in 12.5mV steps (Default: -4V) Programmable output voltage by ASWIRE from 6.5 V to 8.0V in 50mV or in 100mV steps (Default: 7.6V) Max Output current for ELVDD and ELVSS 1000mA @ VIN=2.5V, ELVDD=4.6V, ELVSS= -4V 1000mA @ VIN=2.7V, ELVDD=4.6V, ELVSS= -5.5V 150mA Max Output current for AVDD Short Circuit Protection (SCP) WLCSP 2.017×2.017 - 25B

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AWP37579G_EN_V1.0		英文		2026-06-10
