| Power Supply (Min) (V) |
2.5 |
| Power Supply (Max) (V) |
5.5 |
| PO(W)（8Ω&THD=1%） |
1.26W@5V |
| SPK
Noise(uV) |
17μV@6dB |
| Protection |
/ |
| Control Interface |
Hardware |
| Temperature |
-40℃~85℃ |
| Package (mm) |
EMSOP-8L |
Proprietary TDD Suppression Technology to Effectively Suppress TDD Noise
Excellent PSRR : 85dB(217Hz)
Patented Thermal AGC Function Effectively Protects the Chip from Damage in the Event of Overheating while Providing a Comfortable Listening Experience
Excellent Pop - Click Noise Suppression
Support 1.8V Control Logic
1.26W Output Power (1% THD+N,5V,8Ω Load)
2.65W Output Power (10% THD+N,5V,4Ω Load)
Low Quiescent Current (2.3mA)
Low Shutdown Current (<0.1A)
Operating Voltage Range: 2.5V~5.5V
EMSOP-8L Package
DFN 2X2-8L Package
AW8092 is an upgraded Class AB audio power amplifier with lower noise, an upgrade to AW8090 series.
AW8092 is a dedicated TDD rejection power amplifier with Thermal AGC, 1.26W (8Ω), Class AB audio; The patented Thermal AGC function can effectively protect the device from being damaged under overheating conditions, and avoid the phenomenon that traditional AB products play music intermittently under overheating conditions.
AW8092 has a built-in excellent Pop-Click noise suppression circuit to avoid Pop-Click noise during chip startup and shutdown operations.
AW8092 is capable of delivering 1.26W of continuous output power with typically 1% distortion (THD+N) when it drives an 8Ω speaker from a 5.0V power supply.
AW8092 is available in EMSOP-8L package/DFN 2X2-8L Package. It operates over an ambient temperature range of -40°C to +85°C.
