AW39124QNR-Q1

产品手册：

在线预览 - AW39124QNR-Q1 - 产品手册

参考价格

1-99￥5.38
100-249￥4.41
250-499￥3.55
500-999￥2.80
1000+￥2.15

产品详细信息

参数

Data Rate (Max) (Mbps)	60
VCCA (Min) (V)	1.1
VCCA (Max) (V)	3.6
VCCB (Min) (V)	1.65
VCCB (Max) (V)	5.5
ICCA+ICCB (Max) (μA)	18
Channel	4
Support	Open Drain Push-Pull
Temperature	-40℃~125℃
Transmission Direction	Auto
Package (mm)	QFN 2X1.7-12L

封装 | 引脚 | 尺寸

QFN 2X1.7-12L

特性

Qualified for Automotive Applications No Direction-Control Signal Required Maximum Data Rates -24Mbps (Push Pull), -2Mbps (Open Drain) Power Supply Range: -A Port ａｎｄ VCCA: 1.1V to 3.6 V -B Port ａｎｄ VCCB: 1.65 V to 5.5 V -VCCA ≤ VCCB Pull Up Resistors are Integrated ｉｎ A Port ａｎｄ B Port No Power-Supply Sequencing Required: Either VCCA ｏｒ VCCB Can be Ramped First Support Ultra-Low Power Consumption Mode with OE Pin is Low Voltage Level ESD Protection Exceeds AEC-Q100 A Port: -2000V Human-Body Model (AEC-Q100-002) -1000V Charged-Device Model (AEC-Q100-011) B Port: -8kV Human-Body Model (AEC-Q100-002) -1000V Charged-Device Model (AEC-Q100-011) IEC 61000-4-2 ESD (B Port) -±8kV Contact Discharge -±10kV Air-Gap Discharge

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AW39124-Q1_EN_V1.1		英文		2026-04-14
