AW37334D120FOR

产品手册：

在线预览 - AW37334D120FOR - 产品手册

参考价格

1-99￥1.94
100-249￥1.59
250-499￥1.28
500-999￥1.01
1000+￥0.78

产品详细信息

参数

Load Current (Max) (mA)	300
Power Supply (Min) (V)	1.4
Power Supply (Max) (V)	5.5
Vout (Min) (V)	1.2
Vout (Max) (V)	3.3
Iq (Typ) (μA)	50
Vdropout (mV)	576@IOUT=300mA
PSRR @1KHz(dB)	85@IOUT=30mA
Output Noise (μVrms)	23@IOUT=30mA
Discharge	YES
Output options	Fixed
Temperature	-40℃~85℃
IO Level (V)	1.8
Package (mm)	FOWLP 0.645X0.645-4B

封装 | 引脚 | 尺寸

FOWLP 0.645X0.645-4B

特性

● Input voltage range: 1.4V to 5.5V ● Fixed outputs of 1.2V, 1.8V, 2.8V, 3.0V, 3.3V ● Rated output current: 300mA ● Quiescent current: typical 50µA ● Typical 0.1µA shutdown current ● Very low inrush current ● Typical 184mV dropout voltage(IOUT=300mA, 2.8V output) ● Power supply rejection ratio: typical 85dB (IOUT=30mA, freq=1kHz, 2.8V output) ● Noise: typical 42µVrms (IOUT=30mA, BW=10Hz to 100kHz, 2.8V output) ● Built-in output short protection: typical 120mA when output short to ground ● FOWLP 0.645mm×0.645mm-4B package

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AW37334YXXXFOR_EN_V1.1		英文		2026-01-08
