AW37030D110EDNR

300mA High Performance Low-Dropout Linear Regulator

产品手册：

在线预览 - AW37030D110EDNR - 产品手册

参考价格

1-99￥0.46
100-249￥0.38
250-499￥0.30
500-999￥0.24
1000+￥0.18

产品详细信息

参数

Load Current (Max) (mA)	300
Power Supply (Min) (V)	1.4
Power Supply (Max) (V)	5.5
Vout (Min) (V)	1.1
Vout (Max) (V)	1.1
Iq (Typ) (μA)	50
Vdropout (mV)	680@IOUT=300mA
PSRR @1KHz(dB)	85@30mA, VOUT=3.3V
Output Noise (μVrms)	21@30mA, VOUT=1.1V 46@30mA, VOUT=3.3V
Discharge	YES
Output options	Fixed
Temperature	-40℃~85℃
IO Level (V)	1.8
Package (mm)	DFN 1X1-4L

封装 | 引脚 | 尺寸

DFN 1X1-4L

特性

● Input voltage range: 1.4V to 5.5V ● Fixed outputs of 1.1V, 1.2V, 1.5V, 2.5V, 2.85V, 2.9V, 2.95V, 3.0V, 3.1V, 3.3V ● Rated output current: 300mA ● Quiescent current: typical 50µA ● Typical 0.1µA shutdown current ● Typical 310mV dropout voltage(IOUT=300mA, 1.8V output) ● Power supply rejection ratio: typical 90dB (IOUT=30mA, freq=1kHz, 1.8V output) ● Noise: typical 33µVrms (IOUT=30mA, BW=10Hz to 100kHz, 1.8V output) ● Built-in output short protection: typical 120mA when output short to ground ● DFN 1mm×1mm×0.37mm-4L package

技术文档

	类型	项目标题		语言		日期
	产品手册	DS_AW37030YXXXE_EN_V1.2		英文		2025-11-05
