AW35113FOR

2A Ultra-small Load Switch with Slew Rate Control

产品手册：

在线预览 - AW35113FOR - 产品手册

参考价格

1-99￥1.35
100-249￥1.10
250-499￥0.89
500-999￥0.70
1000+￥0.54

产品详细信息

参数

Channel	1
Controlled Slew Rate	YES
Enable Logic	Active High
Output Discharge	YES
Reverse Current Block	YES
TR (μs)	274
Max Continuous Current (A)	2
Ron (mΩ)	64
Power Supply (Min) (V)	1
Power Supply (Max) (V)	5.5
Temperature	-40℃~85℃
IO Level (V)	1.8
Package (mm)	FOWLP 0.9X0.9-4B

封装 | 引脚 | 尺寸

FOWLP 0.9X0.9-4B

特性

● Integrated P-channel MOSFET load switch ● Input voltage: 1V to 5.5V ● 2A maximum continuous switch current ● Switch on-resistance(typ.): Rdson=52mΩ at VIN=5.5V Rdson=57mΩ at VIN=4.2V Rdson=64mΩ at VIN=3.3V Rdson=76mΩ at VIN=2.5V Rdson=100mΩ at VIN=1.8V Rdson=164mΩ at VIN=1.2V Rdson=230mΩ at VIN=1V ● Controlled slew rate to limit inrush currents ● Ultra low shutdown current ● Internal EN pull-down/up resistor ● Quick Output Discharge(QOD) for AW35111/ AW35113/AW35114 ● Full time Reverse Current Protection (RCP) for AW35112/AW35112B/AW35113 ● FCDFN 0.8mm×0.8mm-4L package FOWLP 0.8mm×0.8mm-4B package FOWLP 0.9mm×0.9mm-4B package

技术文档

	类型	项目标题		语言		日期
	产品设计指南	AW3511X 硬件设计指南		中文		2024-03-25
	产品手册	DS_AW3511X_EN_V1.8		英文		2026-07-23
