AW32F001QNR-Q1

24MHz 32-bit General Automotive MCU

产品手册：

在线预览 - AW32F001QNR-Q1 - 产品手册

参考价格

1-99￥26.92
100-249￥22.07
250-499￥17.77
500-999￥14.00
1000+￥10.77

产品详细信息

参数

Core	M0+
fₘₐₓ(MHz)	24
Flash(KB)	60
RAM(KB)	16
Dataflash(KB)	-
I/O	16
DIV	Y
DMA	-
CRC	Y
Adv Timer	-
GP Timer	-
Ba Timer	-
LP Timer	-
WDG	2*WDT
RTC	-
U(S)ART	1
LP UART	-
I2C	1
I3C(Slave/Master)	-
SPI	-
I2S	-
USB2.0	-
CAN2.0B	-
LIN	-
ADC(ch、bit、Msps)	1*(10、14、0.1)
DAC	-
COMP	-
OPA	-
PGA	-
VS	-
IEXC	-
CAP	-
Segment LCD	-
LED/RGB	-
Package	WBQFN40
Package Size	5x5
VDD(V)	2.0~5.5
Temp(℃)	-40~105
Special Features	AECQ-100 G2, temp detection

封装 | 引脚 | 尺寸

QFN 5X5-40L

特性

1、AECQ-100 Grade 2: -40~105℃ 2、24MHz 32-bit MCU 3、4KB LDROM, 60KB Flash, 16KB SRAM 4、100 K SPS 14 bit SAR ADC 10 chanels differential input 5、CRC32 and High-speed divider 6、2 x 32-bit timer, 7、2 watch-dog 8、Support 1MHz I2C 9、Support UART 10、16 GPIO pins 11、Power-on reset, Low voltage detection 12、Low voltage reset and temperature detection 13、Support In-System Programming (ISP) & In-Circuit Programming (ICP) 14、Low power mode 15、QFN 5.0mmX5.0mmX0.75mm-40L package
