| Channel |
24 |
| Global Current Level |
2 |
| Current Levels for Color-Mixing |
256 |
| Current Levels for Dimming |
256 |
| Charging Indicator |
NO |
| Control Interface |
IIC |
| Power Supply (Max) (V) |
5.5 |
| Global Max Current(mA) |
35 |
| IO Level (V) |
1.8 |
| Audio Sync. |
NO |
| Power Supply (Min) (V) |
2.7 |
| Auto Breath |
NO |
| Temperature |
-40℃~105℃ |
| Topology |
Linear |
| Package (mm) |
QFN 4X4-32L |
1. 24-channel RGB LED Driver
2. Independent 12-bit PWM modulation
(1) Independent color mixing register per channel
(2) Independent brightness register per RGB LED group
(3) Linear or logarithmic brightness control
3. Maximum output current: 25.5mA or 35mA
4. High-precision current sinks
(1) Device to device error：±7%
(2) Channel to channel error：±7%
5. LED Bank control
(1) 3 banks for RGB LED color control
(2) 1 bank for RGB LED brightness control
6. Power save mode when all LED off > 30ms
7. Over temperature protection
8. 400kHz I2C interface, 4 independent addresses, 1 broadcast address
9. Power supply: 2.7V to 5.5V
10. QFN 4mm x 4mm x 0.85mm 32L package
AW26024 is a 24-channel high precision constant current LED driver. Each channel integrates independent 12-bit PWM generator which is composed of 8-bit brightness register and 8-bit color register. The maximum current of each channel is recommended to be configured via external resistor REXT.
AW26024 can be turned off with minimum current consumption by pulling the EN pin low. When EN pin pull high and all LEDs off >30ms, AW26024 enters power save mode.
AW26024 is available in QFN 4mm x 4mm x 0.85mm-32L package. It operates from 2.7V to 5.5V over the temperature range of -40℃ to 105℃.
