| Channel | 1 |
| Power Supply (Min) (V) | 1.8 |
| Power Supply (Max) (V) | 5.5 |
| Vos@25℃ (Max) (mV) | 1.6 |
| Vos TC (Typ) (µV/℃) | 1 |
| GBW (Typ) (MHz) | 1 |
| Slew rate (Typ) (V/us) | 2 |
| Iq per channel (Typ) (mA) | 0.066 |
| Vn @ 1 kHz (Typ) (nV/rtHz) | 30 |
| CMRR (Typ) (dB) | 103 |
| Rail-to-rail | in,out |
| Temperature | -40℃~125℃ |
| IB (Typ) (pA) | 1 |
| Package | DFN 0.8X0.8-5L |
| DFN 0.8X0.8-5L |
|
タイプ
|
タイトル
|
言語
|
日付 | |||
|---|---|---|---|---|---|---|
| Product Design Guide | AWS90001 硬件设计指南 | 中文 | 2025-08-07 | |||
| Product Design Guide | AWS90001 Hardware Design Guide | 英文 | 2026-04-15 | |||
| Datasheet | DS_AWS90001_EN_V2.4 | 英文 | 2026-04-16 | |||
| Technical articles | 【技术帖】开年第一篇干货——鼎鼎大名的运算放大器，你知多少？ | 中文 | 2023-01-30 |
評価ボード
AWS90001 DEMO V1.0 — AWS90001 EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS90001DNR.
This EVB is an evaluation motherboard used for operational amplifiers
評価ボード
AWS90001 DEMO V1.0 — AWS90001 EVB is an evaluation board for awinic low-power low-voltage and rail-to-rail operational amplifier AWS90001DNR.
This EVB is an evaluation motherboard used for operational amplifiers
